Intel® Core™ i7-9700K Processor
12M Cache, up to 4.90 GHz
Essentials
| Product Collection | 9th Generation Intel® Core™ i7 Processors |
| Code Name | Products formerly Coffee Lake |
| Vertical Segment | Desktop |
| Processor Number | i7-9700K |
| Lithography | 14 nm |
| Included Items | Please note: The boxed product does not include a fan or heat sink |
| Use Conditions | PC/Client/Tablet |
Performance Specifications
| # of Cores | 8 |
| # of Threads | 8 |
| Processor Base Frequency | 3.60 GHz |
| Max Turbo Frequency | 4.90 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| ntel® Turbo Boost Technology 2.0 Frequency‡ | 4.90 GHz |
| TDP | 95 W |
Memory Specifications
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-2666 |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 41.6 GB/s |
| ECC Memory Supported ‡ | No |
Processor Graphics
| Processor Graphics | Intel® UHD Graphics 630 |
| Graphics Base Frequency350 MHz | 1.20 GHz |
| Graphics Video Max Memory | 64 GB |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI 1.4)‡ | 4096×2304@24Hz |
| Max Resolution (DP)‡ | 4096×2304@60Hz |
| Max Resolution (eDP – Integrated Flat Panel)‡ | 4096×2304@60Hz |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| # of Displays Supported ‡3 | 3 |
| Device ID | 0x3E98 |
Expansion Options
| Scalability | 1S Only |
| PCI Express Revision | 3 |
| CI Express Configurations ‡ | Up to 1×16, 2×8, 1×8+2×4 |
| Max # of PCI Express Lanes | 16 |
Package Specifications
| Sockets Supported | FCLGA1151 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2015D |
| TJUNCTION | 100°C |
| Package Size | 37.5mm x 37.5mm |
Advanced Technologies
| Intel® Optane™ Memory Supported ‡ | Yes |
| Intel® Turbo Boost Technology ‡ | 2 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Hyper-Threading Technology | No |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology ‡ | Yes |
| Intel® Stable Image Platform Program (SIPP) | Yes |
Security & Reliability
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® ME |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
