Name: MSI MAG B550M BAZOOKA
SKU: NG00037
Price: 15299.00 INR
Availability: OutOfStock

Conquer the Battlefield

The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.

Support for 3rd Gen AMD Ryzen™ Processors and future AMD Ryzen™ processors with BIOS update
Supports DDR4 Memory, up to 4400+(OC) MHz
Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr
Premium Thermal Solution: Extended Heatsink Design with additional choke thermal pad rated for 7W/mk and PCB with 2oz thickened copper are built for high performance system and non-stop gaming experience.
Gigabit LAN with LAN Manager: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
Enhanced Power Design: 4+2+1 Duet Rail Power System, Digital PWM, Core Boost, DDR4 Boost.
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience.
Flash BIOS Button with Optmized ClearCMOS Function: Simply use a USB key to flash any BIOS within seconds. Restore the BIOS to the default settings without any additional actions.

CPU

Supports AM4 socket 3rd Gen AMD Ryzen^™ processors, and future AMD Ryzen^™ processors with BIOS update

See supported processors

CHIPSET

AMD B550 Chipset

MEMORY

4x DDR4 memory slots, support up to 128GB ¹
- Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
- Supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400+ MHz by A-XMP OC MODE
  - 1DPC 1R max speed 4400 MHZ
  - 1DPC 2R max speed 3733 MHZ
  - 2DPC 1R max speed 3866 MHZ
  - 2DPC 2R max speed 3466 MHZ
Dual channel memory architecture
Supports non-ECC UDIMM memory
Supports ECC UDIMM memory (non-ECC mode)
Supports un-buffered memory

Please refer www.msi.com for more information on compatible memory.

See supported memory

EXPANSION SLOT

1x PCIe 3.0/ 4.0 x16 slot (PCI_E1) ¹
2x PCIe 3.0 x1 slots

The supported specification depends on installed processor.

ONBOARD GRAPHICS

1x DisplayPort, supports a maximum resolution of 4096×2160 @60Hz ¹
1x HDMI port, supports a maximum resolution of 4096×2160 @24Hz ¹
Maximum shared memory of 16GB

Available for the processor with integrated graphics.

STORAGE

AMD B550 Chipset

4x SATA 6Gb/s ports
2x M.2 slots (Key M)
- M2_1 slot (from AMD processor)
  - Supports PCIe 4.0/ 3.0 x4 ¹
  - Supports SATA 6Gb/s
  - Supports 2242/ 2260/ 2280 storage devices
- M2_2 slot (from AMD B550 chipset)
  - Supports PCIe 3.0×4
  - Supports 2242/ 2260/ 2280 storage devices

The supported specification depends on installed processor.

RAID

AMD B550 Chipset

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

USB

AMD B550 Chipset

3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)
6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)

AMD Processor

4x USB 3.2 Gen 1 5Gbps Type-A ports (4 Type-A ports on the back panel)

AUDIO

Realtek^® ALC892 Codec

7.1-Channel High Definition Audio

LAN

1x Realtek^® RTL8111HN 1Gbps LAN controller

INTERNAL CONNECTORS

1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x M.2 slots (M-Key)
1x USB 3.2 Gen 1 5Gbps Type-C port
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
3x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Serial port connector
1x Chassis Intrusion connector
2x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
1xTPM module connector
1x Clear CMOS jumper
