SPECIFICATIONS
| Model No. | SST-ML08B (black) SST-ML08B-W (black + window) SST-ML08B-H (black + handle) SST-ML08B-HW (black + handle & window) | |
| Material | Reinforced plastic outer shell, steel body | |
| Motherboard | Mini-ITX | |
| Drive bay | External | Slim optical 12.7mm or 9.5mm x 1 |
| (9.5mm compatibility limited to tray type) | ||
| Internal | 2.5″ x 2 (one additional 3.5″ or 2.5″ space depending on expansion card installed) | |
| Cooling system | Front | — |
| Rear | Passive exhaust vents | |
| Side | Oversized vents over CPU/motherboard and expansion area | |
| Top | — | |
| Bottom | — | |
| Internal | — | |
| Expansion slot | 2 | |
| Front I/O port | USB 3.0 x 2 audio x 1 MIC x 1 | |
| Power supply | SFX & SFX-L | |
| Expansion card | *Compatible up to 13″ (330mm) long, width restriction-4.78″ (121mm) | |
| Limitation of CPU cooler | 58mm | |
| Net weight | 3.2kg~3.5kg | |
| Dimension | 380mm (W) x 87mm (H) x 370mm (D), 12 liters 14.96″ (W) x 3.43″ (H) x 14.57″ (D), 12 liters | |
| Extra | Support two Kensington locks PCI Express riser card set x 1 | |
| Remark |
| *Expansion card holder needs to be removed when installing expansion/graphics card wider than 4.78 inches (121 mm). When system is assembled without the holder, vertical orientation of the case is recommended and transporting/shipping should be avoided. For more details, please refer to manual. |
