Description
TENDA N301 Wireless N300 Easy Setup Router
What It Does
The N301 Wireless N300 Easy Setup Router is designed to setup more easily for the home user. It complies with IEEE802.11n, delivers wireless speeds of up to 300 Mbps, making it perfect for everyday web activities like e-mail, chatting, streaming videos, online gaming and more. The N301 can also work as a client router to connect ISP network wirelessly or uplink AP to share the Internet to every corner,elimating the dead point.
Main Features
>> Easy setup and enjoy a security wireless network in a minute
>> Wireless security encryption easily at a push of WPS button
>> Work as client to connect ISP network and share the Internet
>> 300Mbps wireless speed ideal for interruption sensitive applications
SPECIFICATIONS
Standard&Protocol | IEEE 802.3/3U IEEE 802.11n/g/b |
Interface | 1 10/100Mbps WAN Port |
| 3 10/100Mbps LAN Ports | |
Antenna | 2 fixed 5dbi Omni Directional antenas |
Button | 1 Reset/WPS Button |
Dimension | 127.4mm*90.5mm*26mm (L*W*H) |
Wireless Link Rate | IEEE 802.11n: up to 300Mbps |
| IEEE 802.11g: up to 54Mbps | |
| IEEE 802.11b: up to 11Mbps | |
Frequency Range | 2.412GHz-2.472GHz |
Working Mode | Universal Repeater |
| AP | |
| WISP | |
| WDS Bridge | |
Wrieless Security | 64/128bit WEP |
| WPA-PSK | |
| WPA2-PSK | |
| WPS support | |
Wireless Function | Enable/Disable Wireless Radio |
| Wireless Access Control | |
Reception Sensitivity | b mode：1M -92dBm@8% 11M -87dBm@8% PER |
| g mode：54M -72dBm@8% PER | |
| n mode：72.2M -68dBm@8% PER； 150M -68dBm@8% PER | |
Internet Connection Type | Dynamic IP、PPPOE、Static IP、L2TP、PPTP |
DHCP Server | Built-in DHCP server |
| DHCP Client List | |
| Address Reservation | |
Virtual Server | Port Forwarding |
| DMZ Host | |
Parental Control | Client Filter |
| Mac Filter | |
| Websites Filter | |
Dynamic DNS | No-IP |
| dyndns | |
VPN Pass-through | PPTP |
| L2TP | |
Other | Bandwidth Control |
| Mac Address Clone | |
| Remote Web Management | |
| System Log | |
Package Content | Wireless N300 Easy Setup Router N301 |
| Quick Installation Guide | |
| Ethernet cable | |
| Power adapter | |
| Resources CD | |
Environment | Operating Temperature: 0℃~40℃ |
| Storage Temperature: -40℃~70℃ | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
Certification | FCC, CE,RoHs |
