Cooler Master MWE GOLD 750 FULL MODULAR PSU
MWE GOLD 750 FULLY MODULAR
Behold the 80 Plus Gold rated, fully modular MWE Gold. This power supply unit delivers consistent 90% efficiency, low temperatures, and quiet operation. High quality, heat resistant components have been used to achieve gold level performance at temperatures up to 45°C. The Silencio fan and exclusive LDB bearing provides nearly silent cooling at no loss to system performance and a longer lifespan. Flat cables improve airflow by reducing cable bulk and a single +12V line ensures all components are fed the same stable output regardless of which cable you use. Be bold, power with gold.
80 PLUS GOLD CERTIFIED
This certification guarantees a typical efficiency of 90% under normal operating conditions.
FULLY MODULAR CABLES
Fully customizable cabling reduces clutter, increases airflow,
and improves overall thermal performance.
ADVANCED CIRCUITRY
The MWE Gold’s full-bridge design coupled with LLC, Synchronous, and DC to DC topology technologies offers reliable and stable voltage outputs.
5 YEAR WARRANTY
This unit comes with a standard limited manufacturing warranty of 5 years from the date of purchase.
SEALED LDB FAN BEARING
The sealed LDB bearing has been combined with Silencio fan technology for quiet cooling with a longer lifespan.
SPECIFICATION
SERIE | MWE Gold Series |
PRODUCT NAME | MWE Gold 750 Full Modular |
MODULAR | Full Modular |
MODEL | MPY-7501-AFAAG |
ATX VERSION | ATX 12V V2.31 |
PFC | Active PFC (>0.95 typical) |
INPUT VOLTAGE | 100-240V |
INPUT CURRENT | 12-6A |
INPUT FREQUENCY | 50/60Hz |
DIMENSIONS (L X W X H) | 160 x 150 x 86 mm |
FAN SIZE | 120mm |
FAN BEARING | LDB |
POWER GOOD SIGNAL | 100-500ms |
HOLD UP TIME | >14ms at 100% load |
EFFICIENCY | 90% Typically |
ERP 2013 LOT 6 | Yes |
MTBF | >100,000 Hours |
OPERATING TEMPERATURE | 0-45°C |
PROTECTIONS | OVP, OPP, UVP, SCP, OTP, OCP |
REGULATORY | CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
MB 24-PIN CONNECTORS | 1 |
CPU 12V 4+4 PIN CONNECTORS | 1 |
CPU 12V 8 PIN CONNECTORS | 1 (for updated models) |
SATA CONNECTORS | 8 |
PERIPHERAL 4-PIN CONNECTORS | 6 |
FDD CABLE 4-PIN CONNECTORS | 1 |
PCI-E 6+2 PIN CONNECTORS | 4 |
80 PLUS | Gold |
WATTAGE | 500 to 750W |
