Description
Technical Spec.
GPU Engine Specs: | |
---|---|
CUDA Cores | 768 |
Boost Clock (MHz) | 1392 |
Base Clock(MHz) | 1290 |
Thermal and Power Spec: | |
Minimum System Power Requirement (W) | 400 |
Memory Specs: | |
Memory Clock | 7Gbps |
Standard Memory Config | 4GB |
Memory Interface | GDDR5 |
Memory Interface Width | 128-bit |
Memory Bandwidth (GB/sec) | 168.2 |
Feature Support: | |
NVIDIA Architecture | Pascal |
Microsoft DirectX | 12 API with feature level 12_1 |
NVIDIA Ansel | Yes |
Bus Support | PCI-E 3.0 X16 |
OS Certification | Windows 7-10, Linux, FreeBSDx86 |
NVIDIA G-SYNC™-Ready | Yes |
NVIDIA GPU Boost™ | Yes |
Vulkan API | Yes |
OpenGL | 4.5 |
NVIDIA Encoder | Pascal |
NVIDIA Decoder | Pascal |
Graphics Card Dimensions: | |
Length | 195mm |
Height | 99.8mm |
Width | 2-slot |
Display Support: | |
Multi-Monitor | Yes |
Maximum Digital Resolution | 7680×4320 |
HDCP | 2.2 |
Standard Display Connectors | Dual-Link DVI-D, HDMI 2.0b, DisplayPort 1.4 |
