Cooler Master MASTERWATT 750 PSU
The MasterWatt is an 80 Plus Bronze power supply with an innovative semi-fanless mode. Under 15% load,the MasterWatt fan remains idle,offering zero dBA. When demand for power increases,a gradual fan curve provides measured cooling with little to no noise at any output level. Dual forward / DC-to-DC topology is employed to keep the voltage stable in all conditions. For increased performance,MasterWatt is equipped with 16 AWG power cables,which reduces resistance,thereby increasing efficiency.
80 PLUS BRONZE CERTIFIED
The 80 PLUS Bronze certification guarantees that MasterWatt delivers an average efficiency of 85%.
SPECIFICATION
| PRODUCT NAME | MasterWatt 750 |
| MODULAR | Semi Modular |
| MODEL | MPX-7501-AMAAB |
| ATX VERSION | ATX 12V v2.4 |
| PFC | Active PFC |
| OPERATION VOLTAGE | 100-240Vac |
| INPUT VOLTAGE | 100-240Vac |
| INPUT CURRENT | 10-5A |
| INPUT FREQUENCY | 50-60Hz |
| DIMENSIONS (L X W X H) | 140 x 150 x 86 mm |
| FAN SIZE | 120mm |
| FAN BEARING | LDB |
| POWER GOOD SIGNAL | 100-500ms |
| HOLD UP TIME | 16ms at 80% Load |
| EFFICIENCY | 85% @ Typical Load |
| ERP 2013 LOT 6 | Yes |
| MTBF | >100,000 Hours |
| OPERATING TEMPERATURE | 0-40°C |
| PROTECTIONS | OCP, OVP, UVP, OPP, OTP, SCP |
| REGULATORY | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| MB 20+4 PIN CONNECTORS | 1 |
| CPU 12V 4+4 PIN CONNECTORS | 1 |
| SATA CONNECTORS | 9 |
| PERIPHERAL 4-PIN CONNECTORS | 3 |
| FDD CABLE 4-PIN CONNECTORS | 1 |
| PCI-E 6+2 PIN CONNECTORS | 4 |
| 80 PLUS | Bronze |
| WATTAGE | 500 to 750W |
| SERIE | MasterWatt Series |
