SilverStone ST50F ES230 500W SMPS

₹2,350 (In. GST)

+ (Free Shipping)

High efficiency with 80 PLUS certification

￭ 24/7 continuous power output with 40℃ operating temperature

￭ Class-leading single +12V rail

￭ Active PFC Circuitry

￭ PCI-E 8pin and PCI-E 6pin connector support

￭ Silent running 120mm fan with 18dBA

Out of stock

Guaranteed Safe Checkout

Silverstone st50f-es230 500 watt



SPECIFICATION

Model No.
SST-ST50F-ES230
Max. DC Output
500W
Power density
277W per liter
Load Range
Output
+3.3V+5V+12V+5VSB-12V
Max.(Amps)
18A17A38A2.5A0.3A
Peak (Amps)
/////
Min.(Amps)
0A0A0A0A0A
Range (%)
±5%±5%±5%±5%±10%
Line Reg.(%)
±1%±1%±1%±1%±1%
Ripple(mVp-p)
50mV50mV120mV50mV120mV
Combined +3.3V & +5V
110W
Combined +12V
456W
Input Voltage
180 ~ 264Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC.（PF>0.9 at Full Load）
Efficiency
82%~85% @ 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection
Over voltage protection
Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector（500mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
2 x 8 / 6-Pin PCIE connector（”500mm / 150mm”）
2 x SATA connector and
1 x 4-Pin Peripheral connector and
1 x 4-Pin Floppy connector （500mm / 150mm / 150mm / 150mm）
2 x SATA connector and
2 x 4-Pin Peripheral connector（500mm / 150mm / 150mm / 150mm）
Cooling System
Silent 120mm fan
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91″ (W) x 3.39″ (H) x 5.51″ (D)
Weight
1.31kg
Certification
80 PLUS
Other
GPU Support list
Compatible with ATX12V v2.4
